Microscopic Analysis
In our materials testing laboratory we offer microscopic analysis, manual and automatic quality control of samples, determination of dimensions and analysis of the material structure.
-
Over 30 years of experiencein the supply & service of testing technology
-
Warranty & post-warranty servicefor our own and competitors' equipment
-
Training of your employeesto increase their expertise
-
Accredited laboratoriesfor external tests and calibrations
Microscopic analysis
Our laboratory offers services in the field of materials analysis using the most modern technologies.
We provide image documentation for detailed visualisation of structures, interactive measurement for precise and flexible evaluation of samples, and automatic image analysis, which ensures fast and objective results.
We also specialise in specific measurements according to the nature of the material and offer analyses tailored to the individual requirements of customers.
Thanks to the combination of expertise and innovation, we are a reliable partner for research, development and quality control.
Evaluation of test results
We carry out visual inspection after mechanical, climatic and vibration tests. We evaluate above all the size of cracks, material degradation, material corrosion and material failure.
Optical inspection of electronics
We inspect electronics and printed circuit boards (PCB) both regularly after production runs and as individual products. We are able to measure the position and orientation of components or to check the quality of soldering, manufacturing or individual layers.
Measurement of welds and porosity
Microscopic evaluation of a weld serves for a detailed assessment of the internal structure of the weld metal, the heat-affected zone and the base material. Observed, for example, are the size and shape of grains, uniformity of structure, the presence of phases or possible defects such as cracks or inclusions that are not visible to the naked eye.
Thickness of layers and coatings
For an accurate assessment of the quality of these layers, the optical microscopic method is used, which allows direct measurement of the thickness on a cross-section of the sample. During measurement the interface between the coating and the substrate is visually observed, whereby it is possible to accurately determine not only the layer thickness, but also its uniformity and adhesion quality.
Grain size
We carry out material analysis, above all for measuring single-phase structures (e.g. austenite, aluminium)
Measurement of two-phase structures (e.g. ferrite-austenite, ferrite-pearlite)
Various measurement methods: planimetric, linear, circular, Abrams, comparison charts.
Own measurement methodologies.
Measurement according to standards:
- ASTM E112-13 (2013)
- ASTM E1382-97 (2015)
- ISO 643 (2012)
- JIS G 0551 (2013)
- GB/T 6394 (2017)
Cast iron
Analysis of cast iron for the classification of graphite in cast iron according to standards:
- ISO 945-1 (2006)
- ASTM A247-06 (2006)
- JIS G5502 (2007)
We are also able to use measurement of the ferrite/pearlite ratio or your own measurement methodologies.
We'll be happy to advise you.
Ing. Radek Lovětínský
Head of the testing laboratory
What our laboratory offers
In our microscopic analysis laboratory we specialise in the detailed evaluation of materials and their structures. We provide precise measurement of the dimensions of microscopic objects and verify their conformity with drawing documentation. We measure the thickness of various layers – coatings, paints or oxide layers – and evaluate their uniformity. In the field of welding technology we focus on measuring the geometric parameters of welds, analysing their structure and the heat-affected zone.
Scope of tests
- Material structure
- Dimensional inspection
- Grain size
- Weld measurement
- Measurement of layer and coating thickness
- Dimensional inspection of electronics
What We Test for You
Measurement of layer thickness
Optical measurement of thickness of surface layers after prior preparation by grinding and polishing. Measurement of linear layers, circular layers, general layers, calotest.
Weld inspection
Measurement of dimensions of welds according to your internal specifications and standards: fillet, lap, spot and butt weld dimensions, defects.
Material structure
Evaluation of the microstructure on sections of samples.
Which standards we test for you
Since there are countless regulations and standards in the field of materials testing, it is essential to carefully study, for every order, all the standards according to which the customer requires testing. We have access to a portal with standards from which we can download them, so in most cases it is enough to give us the designation of the standard.
